laser engraving acrylic ZK-4040-40W(400*400mm)
Machine of laser engraving acrylic :
Features of laser engraving acrylic :
1. USB Port to desktop or laptop computer.
2. SHENZHOUYIKE control software,this is a coreldraw plug-in,if you
can use coreldraw,
you can control the machine easily.
3. 40W CO2 laser tube, most suitable for engraving.
4. Red position system, high precision positioning.
5. Honey comb working table, better for software materials
engraving & cutting.
6. Supporting graphic formats, such as EMF/JPG/PLT/WMF.
7. Cold rolled steel machine body ,high bearing capacity,long life
use.
8. Exhaust fan to cool all electronic component's temperature.
9. Leadshine stepper motor and driver ,make the high precise and
good performance.
Applicate industry of laser engraving acrylic :
Advertising industry, seal engraving, craft industry, leather
engraving& cutting, cloth engraving &cutting, model making,
architects models, packing& printing industry.
Application materials of laser engraving acrylic :
wood, bamboo, organic glass, plastic, cloth, paper, leather,
rubber, sponge, coconut shell, double color boards, acrylic,
marble, granite, jade, crystal , and other nonmetal, also can
processing the cylindrical objects, such as glass, pen container,
writing brush, trophy.
Parameter of laser engraving acrylic :
Working area | 400*400mm |
Laser type | Co2 glass |
Laser power | 40W(options:50W,60W) |
Laser tube(life hour) | 1500-2300 hours |
Engraving speed | 0-350mm/s |
Minimum Shaping Character | Chinese 2mm Letter 0.8mm |
Resolution Ratio | 0.025mm |
Resetting Positioning | 0.01mm |
Working table | Honey comb |
Motor Type | Stepper Motor. |
Software supported | SHENZHOUYIKE software ,and plug-in of coreldraw |
Interface to Computer | USB Port |
Current | 0~22mA |
Power consumption | ≤250W |
Power supply | AC 110V 50/60Hz or AC 220V 50/60Hz |
Graphic format supported | BMP/JPG/JPEG/WMF/EMF/PLT |
Water cooling | Water pump included |
Operating temperature | 0-45 ℃ |
Working humidity | 8-95% |
Samples of laser engraving acrylic :
